Reverse Engineering & 3D Scanning

Reproduce a part that has no drawing. We scan it and build an accurate 3D CAD model, simple or complex.

Reverse Engineering & 3D Scanning
You send
Your existing part
We scan it
3D scanning to a point cloud or STL
You get
A parametric or NURBS CAD model
Then
We can machine it or build tooling to cast it
A laser scans a cast pump housing into a point cloud, the points become a triangle mesh, then a clean CAD model that is checked against the scan.

Need to reproduce a part, but there is no drawing or CAD file? Whether it is simple or complex, worn, broken or obsolete, we can turn it into an accurate 3D model. All we need is the part.

We 3D scan your part to capture its shape as a point cloud or STL model. From that scan data we use CAD software built for reverse engineering to create either a parametric or a NURBS-based model, depending on what you need it for.

Once the model is done, we can machine new parts, build foundry tooling to cast it, or simply hand you the files.

What to send for a quote

  1. The part. A drawing, a CAD file, a sketch or the part itself.
  2. The job. Material and quantity, if you know them.
  3. The date. When you need it in hand.

We reply with a price and a lead time. Quotes are free. Start a quote request
